Description:
-
Rated Voltage: DC5V
-
4-phase
-
Reduction Ratio: 1/64
-
Step Torque Angle: 5.625/64
-
DC Resistance: 200±7% (25)
-
Insulation Resistance: >10M (500V)
-
Dielectric Strength: 600V AC / 1mA / 1s
-
Insulation Grade: A
-
No-load Pull in Frequency: >600Hz
-
No-load Pull out Frequency: >1000Hz
-
Pull in Torque: >34.3mN.m(120Hz)
-
Detent Torque: >34.3mN.m
-
Temperature Rise: <40K(120Hz)
Noise: <40dB (120Hz, No load, 10cm)
Board Size: Approx. 29 ×21 mm
