DC-DC 8A Automatic Step Up Step Down Adjustable Power Module
Module parameters:
Input voltage: DC5-30V Input current: 8A (MAX) peak 10A (6A work a long time) Quiescent current: 4mA (operating voltage is not the same there will be errors) Output voltage: 1.25-30V continuously adjustable Output Current: 10A (MAX) (5A long natural heat inside) Output current range: 0.2-10A Working temperature: -40 to + 85 degrees Operating frequency: 150KHz Conversion efficiency: Typical 91% (12V turn 12V5A) maximum 93% Overcurrent protection: there Short circuit protection: (limiting protection) Overtemperature protection: (automatically reduce the output voltage after overtemperature) Input reverse polarity protection: None, (if necessary, please enter the string into the diode) Output anti-anti-irrigation: Yes, no need for charging plus blocking diode. Connection: Terminal output, (IN is the input, OUT output)
